Drivetrain seal kit 8v Kat 16v integrale
Part No: TB54
Full Gearbox, Front Diff, Transfer Box, Viscous Coupling, Propshaft and Rear Diff Rotary and O ring Seal Kit for Lancia Delta integrale 8v Kat and 16v
For the following Lancia Delta variations (1988-1991):
- Lancia Delta integrale 8v Kat
- Lancia Delta integrale 16v
This kit includes the following parts:
- 40004680 - Gearbox Input Rotary Oil Seal x1
- 10257050 - Copper transmission washer (Transfer box - Front Diff Pipe) x2
- 14461180 - Transfer Box to Viscous Coupling O Ring Oil Seal x1
- 14461980 - Viscous Coupling to RH Driveshaft O ring Oil Seal x1
- 40004720 - Front Differential To LH Driveshaft Rotary Oil Seal x1
- 14460880 - Transfer Box to Front Diff AND Front Diff to LH Driveshaft O Ring Oil Seal x2
- 40004740 - Transfer Box to Propshaft Rotary Oil Seal x1
- 40004730 - Viscous Coupling to RH Driveshaft Rotary Oil Seal x1
- 40004090 - Rear Differential Front Pinion to Propshaft Rotary Oil Seal x1
- 40004580 - Rear Differential to LH Driveshaft Rotary Oil Seal x1
- 14467680 - Rear Differential to LH Driveshaft O Ring Oil Seal x1
- 40004080 - Rear Differential to RH Driveshaft Rotary Oil Seal x1
- 14465680 - Rear Differential to RH Driveshaft O Ring Oil Seal x1
All prices exclude VAT
Associated Products

Gearbox Input Linkage Bush Rotary Oil Seal
Part No: 7659952
Rotary oil seal for the gearbox input linkage bush on the top of the gearbox for Lancia Delta integrale and Evo

Powerflex Gear Rod Support Bush
Part No: PFT-101
Poly bush - fits gear change stabiliser bracket on gearbox for the fixed rod to fit Lancia Delta integrale 8v, 16v, Evo 1 & Evolution 2. Reforms 'sloppy' gear levers! Manufactured exclusively for us by Powerflex.

Propshaft/ Torque Tube Bearing
Part No: 28042330
Propshaft/torque tube rear bearing > differential for Lancia Delta integrale 8v, 16v & Evolution 1 & Evo 2.

Propshaft Support Bracket
Part No: 7614125
Metalastic support for rear propshaft for Lancia Delta integrale 8v, 16v, Evo 1 & Evolution 2.

8v Clutch Fork Bush Top
Part No: 7616758
Bottom: 7616759
No longer available.
